Retrofit Counters

Mainplate Controls retrofit counter replaces your old Rotoflex model URC, C5, C3 counters and Arpeco 115, 600 counters.
We have custom packages for upgrades and retrofits for all other slitter / rewinder inspection equipment (Web Techniques, PIC, Mark Andy and others).

Our retrofits come with a DOS label count sensor and Encoder with Ride-on wheel; allowing for both Length and Label count capability.


Easy to install, fitting into your machine and come with complete installation and operating instructions

Check out some of our latest retofits and upgrades (click to expand):

Mainplate Counter retrofit for Arpeco Elite
Intregrated into exisiting controls of Arpeco Elite to preform all counter functions.
Count, Run speeds, Slowdown, Jog, Strobe trigger pulse + more.
Included: 10", 12", Repeat length, Metric count + Label count.
Options: Fault placement for Vision system + Dual label verification counting for security sensitive requirements.

Mainplate Counter replacing Rotoflex model C3 counter
Included count options: 10", 12", Repeat length, Metric count + Label count.
Options: Fault placement for Vision system is available in all our counters +
Dual label verification counting for security sensitive requirements.

Custom modification to work on any other Printing / Inspection / Slitting equipment to provide Counting,
Fault placement, Strobe trigger pulse and more.

Rotoflex Racer 1300. Manufactured in the 1970's.
This retrofit includes 10", 12", Repeat length, Metric count + Clear on Clear Label count.
Options: Fault placement for Vision system is available in all our counters +
Dual label verification counting for security sensitive requirements.

Mainplate counter with Fault Placement System option



Fault placement for Vision system is available in all our counters & dual label verification counting for security sensitive requirements.



We have custom modifications available to work on any other Inspection / Slitting equipment to provide Counting, Fault placement, dual label verification, strobe trigger pulse and more.

New Mainplate Counter on Table Top with Dual Clear on Clear Pharmaceutical Label verification counting


Controls integrated into existing controls to control Count, Slowdown + Run speeds.
Mismatch Label count alarm provided as standard. Strobe trigger pulse provided.
Other count features included are 10", 12", Repeat length + Metric count.

New controls to replace outdated & failing controls on P.I.C. Industries Rewinder


Controls all functions, Tension, Run speed, Jog & Slow, counting 10", 12", Repeat length, Metric count + Label count.
Options:
Dual label verification counting for security sensitive requirements + Fault placement for Vision system

New AC Motor + AC drive controller with Magnetic brake to replace outdated & failing controls on this Arpeco Tracker


Controls all functions, Automatic Unwind Tension control, Run, Jog, Slowdown speeds, counting 10", 12", Repeat length, Metric count + Label count.


Retrofit provided in your facillity with minimum down time.



Options:
Dual label verification counting for security sensitive requirements + Fault placement for Vision system

Take a photo of the your existing counter and send us an email
Include the any part number(s) and/or the machine serial and model number will help us provide you with

the solution best for you!
